In another demo from the amazing Wes Bos's JavaScript 30 demo, we're using the HTML <video> element, but stripping the not-so-great default controls and installing our own, improved UI. Plus adding some features like skip ahead and playback scrubber.

Embedding a video is easy enough, but it'd be great to have a better handle on the viewing experience, especially if you've got multiple videos for your site—you can customize the UI to match your needs.

The controls—like sliders—seem a bit wonky cross-browser. Wes was awesome and provided the default styles, like he does for every exercise. His lesson didn't go into detail about the styles, but in looking at the stylesheet, there's a whole section marked "unholy css to style input type="range"". So that got me curious, and I spent some time dissecting those specific styles, which I go into below. This is going to be a loooooong post because I want to break down not just the script, but the styles too.

What I'm learning:

  1. Working with HTML5 Video Player
  2. Hiding the default controls, and creating custom ones, like skip ahead and playback speed control
  3. Specifics of styling the video elements and input controls in Webkit browsers

Check out:

Codepen

Github Pages

Github Repo

Basic setup

The <video> element only needs a couple of attributes, a src and a class to style it. We'll have a main <div> to hold the <video>, along with another <div> that will hold the controls. The controls will be a collection of buttons, inputs, and whatever else we want to include.

Here's the complete markup:

<div class="player">
    <video class="player__video viewer" src="https://player.vimeo.com/external/194837908.sd.mp4?s=c350076905b78c67f74d7ee39fdb4fef01d12420&profile_id=164"></video>

    <div class="player__controls">
     <div class="progress">
      <div class="progress__filled"></div>
     </div>
     <button class="player__button toggle" title="Toggle Play"></button>
     <input type="range" name="volume" class="player__slider" min="0" max="1" step="0.05" value="1">
     <input type="range" name="playbackRate" class="player__slider" min="0.5" max="2" step="0.1" value="1">
     <button data-skip="-10" class="player__button">« 10s</button>
     <button data-skip="25" class="player__button">25s »</button>
    </div>

  </div>

Styling the body

Ok, basics in place. Now let's start with the body:

body {
  margin: 0;
  padding: 0;
  background: linear-gradient(135deg, #7c1599 0%,#921099 48%,#7e4ae8 100%);
  background-size: cover;
  display: flex;
  min-height: 100vh;
  align-items: center;
  justify-content: center;
}

Notice how the margin and padding are both set to 0? That's because the user agent stylesheet will often have default margin for the body. Mine did. So it was good to get that set up. I think I'll do this as part of my reset from now.

Ok, next, there's a linear-gradient set. The first arg, 135deg, sets the direction. Then the next 3 values set the "stops" in the gradient—what color it should be at those points, which are 0%, 48%, and 100%.

Then there's the background-size property. I usually use these for background images for <div>s, and I'm embarrassed at how often I get the two values cover and contain mixed up. They both scale the image as big as possible without stretching the image, but here's one big difference:

  • contain does not crop the image
  • cover does crop the image

Since we're only working with a gradient color as background, it doesn't really matter in this case. But just another reminder.

Next, let's look at the positioning we're setting up. We're setting the body up to be a flex container, with the height being the full height of the viewport. We're also saying we want the child container(s) to be centered both vertically and horizonatally...here are the rules that create all of that stuff:

display: flex;
  min-height: 100vh;
  align-items: center;
  justify-content: center;

Styling the main container, div.player

We have one main wrapper within the body, div.player, which holds two child elements: the <video>, and the container for the controls, div.player__controls (thumbs up on the BEM naming conventions).

So div.player has the following styles:

.player {
  max-width: 750px;
  border: 5px solid rgba(0, 0, 0, .2);
  box-shadow: 0 0 20px rgba(0, 0, 0, .2);
  position: relative;
  font-size: 0;
  overflow: hidden;
}

So the border puts a nice little transparent bevel around the player, and the box-shadow give it a lifted effect. Cool.

We also set relative positioning so we can position the child elements. I'm not sure why the font-size is set to 0... Hiding the overflow will let us do the effect where if you hover over the player, the controls will slide up into view; by default, they're hidden away.

Now there are some fullscreen styles we can apply to the parent div.player element. I didn't know that there was a :fullscreen psuedo-class, but there is. According to the docs, it represents an element when it is in fullscreen mode. Huh. Here's the CSS:

.player:fullscreen {
  max-width: none;
  width: 100%;
}

.player:-webkit-full-screen {
  max-width: none;
  width: 100%;
}

It seems strange that we'd have to set these values—eliminating the max-width and explicitly setting the width to be 100%—but there you go. I guess I thought if the element goes full screen, these rules would be in place anyway. There's also a rule with a -webkit- prefix, though when I ran this, the behavior seemed the same on both Chrome and Firefox.

Styling the parent container for the custom controls, div.player__controls

Ok, let's go into the parent container for the custom controls, div.player__controls:

.player__controls {
  width: 100%;
}

The controls container will span the full width of its parent, div.player.

.player__controls {
  width: 100%;
  display: flex;
  flex-wrap: wrap;
}

We're setting up this container element to be a flex container, and overriding the default value of flex-wrap from nowrap to wrap, meaning that child elements will get bumped to the next row if there's not enough space.

.player__controls {
  width: 100%;
  display: flex;
  flex-wrap: wrap;
  position: absolute;
  bottom: 0;
}

By setting the position to be absolute and positioning it at the bottom, we're anchoring this element to a certain position and taking it out of normal flow.

.player__controls {
  width: 100%;
  display: flex;
  flex-wrap: wrap;
  position: absolute;
  bottom: 0;
  transform: translateY(100%) translateY(-5px);
  transition: all .3s;
}

This one had me confused. There are two values for the transform property; the first one moves it all the way out of view (translateY(100%)), and the second brings it back up juuuust a little bit...5px worth. I tried doing this with just a single value for each, and this is what it looked like.

This is for transform: translateY(100%):

One value: transform: translateY(100%

And this is for transform: translateY(-5px):

One value: transform: translateY(-5px)

I thought that the second value would overwrite the first value, but the browser interpreted both, in order.

.player__controls {
  display: flex;
  flex-wrap: wrap;
  width: 100%;
  position: absolute;
  bottom: 0;
  transform: translateY(100%) translateY(-5px);
  transition: all .3s;
}

If we're using the transition property, we're setting up a starting and end state. Here is the starting state, contained in this class, and we're saying to transition all of the properties. We can define an ending state in another class...

.player:hover .player__controls {
  transform: translateY(0);
}

The only thing we're transitioning really is the vertical placement...this class says that when we hover over the parent div.player element, we bring the div.player__controls all the way up (translateY(0)).

.player__controls {
  display: flex;
  flex-wrap: wrap;
  width: 100%;
  position: absolute;
  bottom: 0;
  transform: translateY(100%) translateY(-5px);
  transition: all .3s;
  background: rgba(0, 0, 0, .1);
}

Finally, we just set a little bit of background color on the controls.

Styling the progress bar, div.progress and its child element div.progress__filled

.progress {
  flex-basis: 100%;
}

Remember that div.progress is a direct child of div.player__controls, a flex container. Here, we set the child to take up 100% of the available space, pushing everything else to the next row (remember that we set flex-flow to wrap on the parent container).

.progress {
  flex-basis: 100%;
  position: relative;
}

Setting the position value here means that child element—like div.progress__filled—positions can be set using placement properties like top or left.

.progress {
  flex-basis: 100%;
  position: relative;
  display: flex;
}

The progress bar isn't just a flex child element, but with this line, we set it up to be a flex container as well, allowing for flexbox to be used on div.progress__filled.

.progress {
  flex-basis: 100%;
  position: relative;
  display: flex;
  height: 5px;
  transition: height .3s;
}

If we're using the transition property, that means there's going to be a starting and ending state. The starting state in this case is the height; we'll transition it in a span of .3 seconds with another class where we'll define an ending state.

.player:hover .progress {
  height:15px;
}

This is that ending state; we're saying when you hover over the main container, div.player, the div.progress element will change its height to 15px from whatever its starting state is.

.progress {
  flex-basis: 100%;
  position: relative;
  display: flex;
  height: 5px;
  transition: height .3s;
  background: rgba(0, 0, 0, .5);
  cursor: ew-resize;
}

This is simply setting a background color for the progress bar, and making the cursor look like a double-arrow when you hover over it.

So let's move on the the child element, div.progress__filled:

.progress__filled {
  width: 50%;
  background: #ffc600;
}

Two things: set the default width of this to half of the parent container, and make it a nice bright yellow so we can see it.

.progress__filled {
  width:50%;
  background:#ffc600;
  flex: 0;
  flex-basis: 50%;
}

The flex property is shorthand, and the first value is the flex-grow property. When the value is set to 0, it means that the item won't be resized during calculation to accomodate the flex container's full main axis. The spec for flex-grow states that this number indicates how the element will grow relative to the rest of the flex items; by setting to 0, we're saying it won't grow relative to the other items.

This flex-basis property sets the default space it takes before calculation at 50%...I think these 2 rules together say that we're going to set it at 50% to start off with, but if the container grows/shrinks, don't change it.

Now let's get into the buttons and inputs. There are:

  • 3 buttons. All three have class .player__button, and the first, the toggle play button, also has the class .toggle. The other 2 have differing data-skip attributes.
  • 2 inputs, range sliders. They both have class .player__slider. They also have different values for their name attributes, and different values for their min, max, and step values, which determine the scales for the sliders.

Styling the buttons

Let's start with the class all 3 buttons share:

.player__button {
  max-width: 50%;
  line-height: 1;
  background: none;
  color: white;
  padding: 0;
  border: 0;
  outline: 0;
  text-align: center;
  cursor: pointer;
}

None of these are too confusing. The max-width is setting a sort of outer limit to the width of the buttons, which share space with the range sliders. We align the text symbols to center, and remove background color and make the visible characters white. We also remove the default outline, border, which would also show white otherwise. Padding is removed, and a custom cursor when you hover.

.player__button:focus {
  border-color: #ffc600;
}

If you were to tab through the controls, this puts an indicator around the button if it's in focus.

So the range sliders...this is the stuff that Wes called "unholy."

"Unholy" CSS...styling the input range sliders

We've got 2 sliders that are input[type='range']. Here's what they look like without any styles applied:

Chrome slider input with no styling

Firefox slider input with no styling

input[type="range"] {
  -webkit-appearance: none;
}

According to the documentation for the -webkit-appearance or -moz-appearance prefix, this will "display an element using platform-native styling based on the operating system's theme." Ok. After applying that style, nothing changed.

input[type="range"] {
  -webkit-appearance: none;
  background: transparent;
}

Thinking about functionality in JavaScript

It might be helpful to break it down into these steps:

  1. Get our elements
  2. Build our functions
  3. Hook up our event listeners

Functionality: Toggling the 'Play' button

So we have a button that when you hit it, the video will play or pause. I want to get into some clarifications first.

When we're talking about the HTML <video> tag, we're talking about the HTML element that we use in our markup to embed a video. It will have attributes like src, autoplay, width, and height. We're not really using any of these attributes to control the video, though.

To do that, we're using a DOM Interface called HTMLVideoElement, which has special properties and methods for manipulating video objects. HTMLVideoElement inherits from HTMLMediaElement, which has properties and methods to support audio and video.

So let's grab the <video> player:

const player = document.querySelector('.player');
const video = player.querySelector('.video');

We need a function that will toggle play/pause:

function togglePlay(e) {
  if (video.paused) {
    video.play();
  }
  else {
    video.pause();
  }
}

So viewer has an attribute—paused—which is part of HTMLMediaElement...it's a Boolean. Without having hooked the function up to any event yet, you can test this by calling the function from the console. This should play/pause the video.

Now we want it so this function is called both when you click the video and the play button. We have a selector for the video, let's grab the toggle play button:

const playButton = player.querySelector('.player__button.toggle');

Then we can listen on both of these elements:

video.addEventListener('click', togglePlay);
playButton.addEventListener('click', togglePlay);

Ok, great. But...when the video is paused, the play button still shows the "play" icon, not the pause icon. How do we change it? Here's a scenario I hadn't thought of: there could be multiple reasons why the video is paused that doesn't include when the video or play button are clicked; for example, a popup appears and pauses the video. Because of these other possibilities, it wouldn't be a good idea to put the code for changing the icon in our togglePlay() function. So we'll need another function, one that will listen for if the video has been paused.

Although the video player has an attribute called paused, there are two events we can listen for, play and pause:

video.addEventListener('play', toggleIcon);
video.addEventListener('pause', toggleIcon);

And in the toggleIcon function:

function toggleIcon(){
  const icon = this.paused ? '►' : '❚ ❚';
  playButton.innerText = icon;
}

Here, we can use this because we're adding the event listener directly to the element video. Within the function, we're actually using the attribute paused...if the video is paused, we want the play icon; if it's playing, we want the pause icon.

Functionality: The skip buttons

We've got 2 skip buttons: skip back, and skip ahead. Grab 'em:

const skipButtons = player.querySelectorAll('[data-skip]');

We're querying on the data- attributes here. Though both skip buttons have this attribute, they have different values...one is data-skip = -10, and the other is data-skip = 25.

Here's the function signature for the handler:

function skip() {
  console.log(this.dataset);
}

What's cool about logging this.dataset is that we can see the value of the data- attributes:

Console logging this.dataset for someting with a data- attribute

And we can hook up the event listeners:

skipButtons.forEach(skipButton => skipButton.addEventListener('click', skip));

Notice too that when we assign event listeners, we do it using

skipButton => skipButton.addEventListener('click', skip)

rather than

skipButton => addEventListener('click', skip)

The first one allows us to use this in reference to the element in the event handler; the second makes us use event.target instead of this.

In the handler, we're going to be using the currentTime attribute to set where the video should play from:

function skip() {
  console.log(this.dataset);
  video.currentTime += parseFloat(this.dataset.skip);
}

Note that the value this.dataset is a string, so we have to cast it as a number using parseFloat().

Now, when you click the skip back or skip ahead buttons, the video will skip according to whatever's in that button's data-skip attribute.

Functionality: Range sliders for volume and playback rate

We have the two input sliders, so let's grab them:

const sliders = player.querySelector('[type=range]');

We'll have a function to listen for when these sliders are moved:

function handleSliderUpdate(){
  console.log(this.value);
}

We'll console log the value of the slider after it's been moved.

And now to listen for when the slider is moved...with the buttons, we were listening for a click event. With range sliders, we're listening for a change event:

sliders.forEach(slider => slider.addEventListener('change', handleSliderUpdate))

Now in the <input> tags for boths sliders, we're using a name property. One is name = volume, the other is name = playbackRate. These values are also the names of properties for the video. Here's the volume property and here's the playbackRate property.

Because of that, we can refer to the this.name value to access the properties we want to change:

function handleSliderUpdate(){
  video[this.name] = this.value;
}

Functionality: Progress bar

So here's how we want the progress bar to work:

  • When you play the video, the progress bar should be updating in real time.
  • When you click on it and drag, the video should correspond to that place in the progress bar.

The progress bar is made up of two elements: div.progress (the container) and div.progress__filled, which is the yellow part of the progress bar. On this element, we're going to be changing the flex-basis property to change how much yellow is in the bar. By default, it's set to 50%. You can inspect it and change the values in dev tools to see how it will look at different percentages.

We'll need to grab the progress bar:

const progressFilled = player.querySelector('.progress__filled')

So let's start with a function:

function handleProgress() {
  //handling progress
}

In it, we need a percentage value to work with div.progress__filled's flex-basis value. If 0% is the very beginning of the video, and 100% is the end of the video, we just need to know how long the video is and calculate where it is right now.

We'll need to know 2 different things to figure this out

  1. How long is the video?
  2. Where are we in the video right now?

These things we need to know correspond to 2 attributes of the HTMLMediaElement, duration, which is the length of the video, and currentTime, which is the current playback time.

Within our handler, we can figure out the percentage:

function handleProgress() {
  const progress = (video.currentTime / video.duration) * 100; //gives us what percentage to set flex-basis
}

Then we can set the flex-basis property of the progress bar:

function handleProgress() {
  const progress = (video.currentTime / video.duration) * 100; //gives us what percentage to set flex-basis
  progressFilled.style.flexBasis = `${progress}%`;
}

Great, but when do we run this function? There is an event on HTMLMediaElement called timeupdate that fires whenever currentTime changes. This is what we want: we want the progress bar to reflect how much of the video has played, and we want to be able to go to specific points in the video. So let's set up an event listener:

video.addEventListener('timeupdate', handleProgress);

So now when the video starts, the amount of yellow corresponds to how much of the video has been played. Great!

Now, we want to be able to scrub through the progress bar...basically wherever we click on the progress bar, the video should jump to that point. So let's start off with a function:

function scrub() {
  //scrubbing playback
}

So whenever someone clicks on the progress bar, we want the video to go to that point. So we'll need to listen for a click event on the progress bar. Remember, there's the progress bar (div.progress) and the yellow, filled part (div.progress__filled). The user will be clicking anywhere on the progress bar, not necessarily just on the yellow part, so we need to grab:

const progress = player.querySelector('.progress');

And within the scrub function, let's see what we get in the event:

function scrub(e) {
  console.log(e);
}

We'll need to hook up the event listener on the progress bar:

progress.addEventListener('click', scrub);

So when the progress bar is clicked, we can take a look at what properties are returned. Play around and click in different places, you'll see which property we're looking for...it's offsetX, which is the x position in pixels relative to the progress bar. (Wes mentioned in the video that that's because the position for the progress bar is set to relative, but I'm not sure...I commented out this property, and it seemed to return the same value, so I'm not sure).

Since we know that the event will show which position on the progress bar was clicked—offsetX—it's handy to know that there is a property all elements have called offsetWidth. According to the docs, it returns the layout width of the element. Neat! So we can calculate a percentage of where in the video we're trying to get to based on where in the progress bar was clicked:

function scrub(e) {
  let scrubPercent = (e.offsetX / progress.style.offsetWidth);
}

And if we multiply that percentage by the total length of the video, we'll get where in the video, percentage-wise, we should go:

function scrub(e) {
  let scrubPercent = (e.offsetX / progress.offsetWidth) * video.duration;
}

And finally, just setting the video's currentTime property, which defines where the playback place should be, to the value we just figured out:

function scrub(e) {
  let scrubPercent = (e.offsetX / progress.offsetWidth) * video.duration;
  video.currentTime = scrubPercent;
}

Bingo.

Ok, how about dragging the progress bar to where you want to play? Remember how in the canvas demo we had a flag to determine if the cursor was down, indicating that the pen is down? We're going to do the same thing. If someone has clicked down on the progress bar, then dragged it somewhere, then clicked up, we want the progress to be at the point where they clicked up.

Ok, baby steps. Let's first set it up so that the progress bar will move on a mousemove event, meaning you don't have to click down to move the progress bar:

progress.addEventListener('mousemove', scrub);

So what happens with this is that whenever the mouse moves over the progress bar, the video is going to jump to that point. If you move the mouse really fast, the video's going to choke a bit because it has to catch up. Not ideal. So we want to set up the mouse up/down functionality.

We'll need a flag:

let mousedown = false;

It's intially set to false because well, the mouse isn't down by default.

Now, some event listener chicanery:

progress.addEventListener('mousemove', scrub);
progress.addEventListener(`mousedown`, () => mousedown = true)
progress.addEventListener('mouseup', () => mousedown = false)

I've included the line to listen for mousemove on the progress bar just for context. But what's happening in the callback functions for these events:

  • If the mouse is clicked down while on the progress bar, flip the flag to true.
  • If the mouse is clicked up while on the progress bar, flip the flag back to false.

By the way, I initially had semicolons at the end of the expressions in the mousedown and mouseup callbacks, so:

progress.addEventListener(`mousedown`, () => mousedown = true;)
progress.addEventListener('mouseup', () => mousedown = false;)

And I was getting an Uncaught SyntaxError: missing ) after argument list message. After deleting the semicolons, the errors went away. I'm still getting the hang of the arrow functions as callbacks I guess.

Now, in the line where we listen for the mousemove event on the progress bar, we do this:

progress.addEventListener('mousemove', () => {
  if (mousedown) {
    scrub();
  }
});

What this says if if the mouse is being moved and flag is true—ie, the mouse is down—then we call our scrub() function. The syntax can be cleaned up to be this:

progress.addEventListener('mousemove', (e) => {mousedown && scrub(e)});

Here, we're using the logical && operator to check for two conditions...this says that scrub() will only be called if both conditions are true—the flag has to be true. And because the scrub() function is taking in the event as an argument, we pass it within the callback.

Functionality: Fullscreen mode

This one's pretty easy. First, let's add a fullscreen button to our markup:

<button class="player__button fullscreen">FS</button>

I had a hard time finding a fullscreen icon, and I didn't want to use a library like Font Awesome just for this demo, so for the purpose of just showing functionality, the button text reads 'FS'. Fine for now. In our script, we'll need to grab this element:

const fullScreenButton = player.querySelector('.fullscreen')

We'll have a function to handle a click event on this button:

function toggleFullScreen() {
  //do some fullscreen toggling
}

And we'll set up an event listener:

fullScreenButton.addEventListener('click', toggleFullScreen);

So there's a Fullscreen API for media elements to go fullscreen. It doesn't have full support yet, but we can use it for this demo. The method we want is called requestFullscreen(), and unfortunately we need a vendor prefix in our JavaScript for it. That means we need to first know which vendor we're using.

To do that, we'll use something called window.navigator.userAgent, which returns a string containing info about the type of browser you're using:

const ua = window.navigator.userAgent;

Now, within the toggleFullScreen() event listener, we can detect which browser we're looking for:

function toggleFullScreen() {
  if (ua.includes('Chrome') || ua.includes('Safari')) {
    console.log('webkit')
  };
  if (ua.includes('Firefox')) {
    console.log('firefox')
  }
}

And depending on which browser (not looking at you in this demo, Explorer/Edge), we can use the appropriate method: either webkitRequestFullScreen() or mozRequestFullScreen():

function toggleFullScreen() {
  if (ua.includes('Chrome') || ua.includes('Safari')) {
    video.webkitRequestFullScreen();
  };
  if (ua.includes('Firefox')) {
    video.mozRequestFullScreen();
  }
}

Note that the method name uses a capital "S", while the default API method uses a lowercase "s".

Resources
